This Vehicle is Not Made to be Used on Public Roads.
Surron’s new Ultra Bee is the bike you have been waiting for since Light Bee hit the market a few years back. The 2024 Ultra Bee will be sold as an off-road model, and it can’t be registered as a street-legal motorcycle at the DMV.
Surron’s new Ultra Bee takes electric performance to a whole new level. Surron’s latest powertrain system is at the heart of this mid-sized powerhouse. The newly designed platform delivers precision lightweight handling, smooth power output, and integrates Surron’s refined off-road traction control system (SRTC) to help conquer obstacles on your ride.
A refined, race-inspired braking system will boost stopping power on the trails, while the unique TR rear suspension and new front suspension will inspire you to go faster, jump farther, and ride with confidence.
Featuring a newly designed suspension system with 9.4 inches (240 mm) of travel front & back, the new Ultra Bee offers a wider range of adjustability for various conditions. The new forged aluminum frame’s dark green look helps the Ultra Bee further stand out in the crowd
KEY FEATURES:
12.5 KW
PEAK POWER |
87 MILES (140 KM)
MAXIMUM RANGE |
56 MPH (90 KM/H)
TOP SPEED |
2.3 SECONDS
0-50 KM/H |
SPORT/ECO/DAILY
RIDING MODES |
SRTC
TRACTION CONTROL |
4 HOURS
RECHARGE TIME |
Tech Specs:
Weight/ Dimensions/ Battery / Motor / Range
- Motor Type: Permanent magnet synchronous motor (PMSM)
- Peak Power: 12.5 kW
- Peak Torque: 440 Nm (325 ft-lbs)
- Top Speed: 90 km/h (56 mph)
- Max Range: 140 km @ 40 km/h (87 miles @ 25 mph), depending upon terrain
- Battery Pack: 74V/55Ah Lithium Ion
- Charging Time: 4 Hours (0-100%)
- Curb Weight: 85 kg (187 lbs)
- Max Load: 100 kg (220 lbs)
- Vehicle Dimensions: 79.1 x 34.6 x 46.4″ (2,010 x 880 x 1,178 mm)
- Ground Clearance: 318 mm (12.5″)
- Wheelbase: 1,380 mm (54.3″)
- Seat Height: 910 mm (35.8″)
Electrical & Lighting
Frame / Suspension / Brakes
- Frame: Forged aluminum alloy
- Swingarm: Forged aluminum alloy
- Front Suspension: 37 mm inverted fork, 240 mm (9.4″) travel, fully adjustable
- Rear Suspension: Adjustable TR Intersect mono-shock, 240 mm wheel travel
- Front Brake: 240 mm hydraulic disc
- Rear Brake: 240 mm hydraulic disc
Wheels & Tires
-
Front Wheel: 19″ wire-spoked rim, 80/100-19 off-road tire
-
Rear Wheel: 19″ wire-spoked rim, 90/90-19 off-road tire
Get ready to revolutionize your off-road adventures with the Sur Ron Ultra Bee, the ultimate electric dirt bike for thrill-seekers and enthusiasts! This beast of a bike is designed to dominate the trails, with a powerful 6kW motor that delivers instant torque and acceleration. With its advanced lithium-ion battery, you’ll enjoy extended ride times and unmatched performance.
The Ultra Bee’s robust design and durable construction can withstand even the toughest terrain, while its adjustable suspension and ergonomic seat ensure a smooth and comfortable ride. Whether you’re carving through single-track trails or tackling rugged hills, this e-bike’s got you covered.
KEY FEATURES
- 12.5 KW PEAK POWER
- 87 MILES (140 KM) MAXIMUM RANGE
- 56 MPH (90 KM/H) TOP SPEED
- 2.3 SECONDS 0-50 KM/H
- SPORT/ECO/DAILY RIDING MODES
- SRTC TRACTION CONTROL
- 4 HOURS RECHARGE TIME
What sets the Sur Ron Ultra Bee apart is its exceptional power-to-weight ratio, making it incredibly agile and responsive. Plus, its near-silent operation means you can sneak up on even the most elusive wildlife. Whether you’re a seasoned pro or just starting out, this bike’s intuitive controls and customizable settings make it easy to dial in your perfect ride.
Experience the rush of electric riding with the Sur Ron Ultra Bee – where power meets precision. Join the e-bike revolution and discover a new level of freedom and excitement on the trails. Order yours today and get ready to unleash the buzz!
Prepare to be blown away by Surron’s new Ultra Bee’s electrifying performance! Surron’s cutting-edge powertrain technology powers this mid-sized machine, providing precision handling, smooth power delivery, and the capacity to overcome any off-road obstacle owing to the integrated Surron traction control system (SRTC). The Ultra Bee will take your riding to the next level, building on the success of its predecessors.
Ultra-light aluminum alloy forged chassis
The compact frame of the Ultra Bee lowers the center of gravity, providing all riders with an unrivaled precise lightweight handling experience.
Lightweight off-road braking system that has been optimized
More reactive braking response, a unique parking mechanism, and the ability to lock the wheel with one hand only.
Balancing On the Cutting Edge
Ultra Bee is based on the design concept of “Balancing On the Cutting Edge,” and it combines an aluminum alloy forged chassis with our 4th generation tiny powertrain, resulting in an 85kg weight that is evenly distributed. This lightweight balanced design is so light that you can lift it with your bare hands. The Ultra bee’s setup may bring trail motorcycle capability to your daily commute, really ushering in the ultra-revolution.
Ultra Bee 74V55AH High Performance Li-ion Battery Pack
The completely new, organized battery pack (4070wh) of the Ultra Bee offers great power density and battery cycle life (up to 1500 times*), as well as an even lower battery discharge temperature rise rate. This novel design increases battery pack reliability and allows for continuous discharge. With a total weight of 20.5kg, the power density is an industry-leading 200Wh/kg.
*After approximately 1500 cycles, the battery pack can still maintain a level of health of more than 80%.
Must I turn off Ultra Bee TC when riding in dirt?
The Surround Traction Control technology (SRTC), which is standard across the Ultra Bee lineup, is the most recent multi-condition off-road traction control technology. The SRTC has three rider selectable settings operated by a single button, allowing the rider to find the best control in any off-road situation.
Ultra Bee Riding Mode Switch
There are four riding modes available: ECO/DAILY/SPORT/Reverse. All of our new designed switches have been ergonomically built so that they are easy to operate, even while you are sprinting through a tight line without taking your eyes off the road. With the enhanced Reverse Mode, you can ride with more confidence, never getting stuck in the path again.
Full Adjustable Suspension System
Featuring a newly designed suspension system with 240mm travel and a wide range of adjustability for ultimate safety and comfort on both dirt roads and city streets. In the case of a fall, the unique chassis design and steering bump stops give further protection from damage.
Riding Anytime
A concealed area under the seat is reserved for the Ultra Bee’s charger. Recharging your Ultra Bee charger on your bike is possible thanks to a designated air-cooling duct. There’s no need to carry a bulky backpack to transport your charger. No need to be concerned about a lack of power. All you need to do now is concentrate on ADVENTURE. You may charge anytime and wherever you wish.
Surron loV System
The Surron IoV (Internet of Vehicle) System comes with a plethora of features, including vehicle general information, remote status checking, ride tracking, antiestrogen safety protection, OTA update, system self diagnostic, and so on.
New Innovative Powertrain
The Surron 4th generation powerplant was specifically built for Ultra Bee. Its unique fully isolated electrical architecture eliminates the possibility of interference between high and low voltage circuit components. The Ultra Bee’s 74V55AH battery pack and 12.5KW / 440N.m torque powertrain make it a lightning fast track or trail weapon that allows you to push your limits to the limit.
Technical Details Surron ULTRA BEE
| Parameter |
Surron ULTRA BEE
Trial
|
Surron ULTRA BEE
OFF Road
|
| Dimension |
2060мм * 880мм * 1178мм |
2010мм * 880мм * 1178мм |
| Curb weight |
88 kg |
85 kg |
| Carrying capacity |
100 kg |
100 kg |
| Ground clearance |
318 мм |
| Wheelbase |
1 380 мм |
| Seat height |
910 мм |
| Front fork travel |
240 мм |
| Rear shock/wheeltravel |
85/240 мм |
| Power system |
PMSM |
| Maximum power(Motor) |
12,5 kW |
| Maximum torque(on wheel) |
440 N.M. |
| Top speed |
>90 km/h |
| Max. range |
140 km (40 km/h) |
| Battery type |
74V55AH Lithium-ion Battery pack |
| Charge time |
4,5 h |
| Frame material |
forged aluminium alloy |
| GPS Terminal |
APP connection (if available) |
| Tyres type |
Front 80/100-19 off-road
Rear 90/90-19 off-road (80/100-19 optional)
|
| Assistance functions |
Surron Traction Control system
Surron Energy Regenerative System
|
Unless otherwise noted, ALL products sold from Sur Ron™ and authorized dealers are sold with the sole intention for off road or race track use only. This product or products may not comply with some State, Federal, Provincial and/or Local laws, ordinances, regulations. The buyer takes full responsibility of the use of these products on their vehicle which may or may not conform to all applicable laws and regulations for on road or highway use.****
