Industrial Cummins Diesel Power

• Powered by a high-performance Cummins QSB5 series diesel engine engineered for dependable commercial and rental-duty operation
• EPA Tier 4 Final and EU Stage IIIA compliant design reduces emissions without requiring a diesel particulate filter (DPF)
• Dual-frequency capability supports both 50Hz and 60Hz applications for flexible deployment across multiple environments
• Advanced electronic engine management system optimizes fuel efficiency, throttle response, and emissions performance
• High-pressure common rail fuel injection system helps reduce engine noise, vibration, and visible exhaust smoke
• Cummins Direct Flow™ air filtration system improves airflow efficiency while extending service intervals
• Dual-stage fuel filtration system enhances fuel cleanliness and water separation for improved engine protection

Advanced Generator Controls

• Commercial-grade digital control platform delivers accurate voltage and frequency regulation under varying load conditions
• Integrated operator interface provides system status monitoring, diagnostics, warnings, and shutdown alerts in one centralized display
• Remote start functionality supported through the engine control module for automated or off-site operation
• Analog engine monitoring gauges include:
  • Oil pressure
  • Coolant temperature
  • Fuel level
  • DEF level
  • Battery voltage
• Digital hour meter allows accurate runtime tracking for maintenance scheduling and fleet management

Stamford Alternator System

• Stamford reconnectable alternator design supports multiple voltage configurations for jobsite flexibility
• Permanent magnet excitation system improves motor-starting capability and non-linear load handling performance
• 12-lead reconnectable alternator configuration simplifies field voltage selection and application versatility

Rental-Ready Enclosure Package

• Heavy-duty sound-attenuated enclosure engineered for reduced operational noise in commercial and urban environments
• Durable white powder-coated steel housing with lockable access doors for added weather protection and security
• Integrated camlock and busbar distribution panel designed for fast power connection and deployment
• Large-capacity fuel system provides up to 24-hour runtime at 75% prime load conditions
• Single-wall fuel tank includes integrated containment basin with leak detection monitoring
• Transport Canada certified fuel tank configuration available for compliant transport applications
• Roof-mounted single-point lifting system simplifies crane loading and jobsite handling
• Cooling package rated for operation in ambient temperatures up to 122°F (50°C) at standby load
• Full engine fluid containment system helps protect against spills and environmental contamination

Multi-Voltage Output Flexibility

Available voltage configurations include:

• 277/480V 3-Phase
• 139/240V 3-Phase
• 120/208V 3-Phase
• 120/240V Single-Phase
• 230/400V 50Hz 3-Phase
• Optional 347/600V 3-Phase configuration available on select models

Shore Power & Cold Weather Support

• Integrated 15A/120V shore power connection supports:
  • Coolant heater
  • Battery charger
  • Engine oil heater
  • Battery warmer
• Heated Human Machine Interface (HMI) display improves visibility and operation in cold-weather conditions

Available Rental Package Options

• Auxiliary fuel and DEF connection kits available for extended runtime applications
• DOT-approved electric brake trailer packages available with:
  • Heavy-duty center jack
  • Ball hitch or pintle hitch options
• DOT-approved hydraulic brake trailer configurations also available for mobile deployment applications
