Features:

• Safe: Prevents dangerous back-feeding to avoid injuring utility line workers.
• Versatile: Can be upgraded later for use with a Generac Home Standby Generator (max 11 kW).
• Universal: Compatible with any portable generator with GFCI protected outlets
• Electronic Rocker Switch: Easily switches from utility to generator power with the simple push of a button
• Power Indicator Lights: Display utility power or generator power.
• Powers hard-wired circuits: Directly powers hard-wired appliances such as a furnace, well pump, and lights.
• Easy to maintain and expand: Interchangeable type circuit breakers make it easy to reconfigure, replace, or expand the circuits in your switch.
• Pre-Wired: for quick and easy installation
• Multi Listed: for use with Siemens, Eaton and Square D 1 inch standard, tandem, GFCI and AFCI breakers for the most flexible and cost effective installation.
• Flexible Mounting Options: Flush or wall mount with left or right exit flexible ENT conduit included

Specifications:

• Max Amps @ 240V: 50 Amp
• Upgradeable for use with a Generac Home Standby Generator (up to 11 kW) : Yes
• Enclosure: Indoor (NEMA 1)
• Circuits Provided: 10
• Max # Circuits: 16
• Included Breakers:
  • 1-30 Amp 2-pole
  • 1-20 Amp 1-pole
  • 2-20 Amp 1-pole
  • 2-20 Amp 1-pole tandem
• Accepts Arc-Fault and GFCI Breakers: Yes
• Prewired: Yes
• Conduit Size: 1-1/4 in. (3.18 cm) ENT with included fittings
• Required Main Breaker in Load Center (provided by installer): 50 Amp 2 pole
• Male Inlet Configuration Outdoor Power Inlet Box: CS6377 NEMA 3R (not included)
• Kit Contents:
  • Transfer Switch
  • Install manual, wiring harness, conduit and fittings
  • 12 in pre-wired whip
• Switch Dimensions (in./cm): 15.4 L x 15.8 H x 4 D / 39.1 L x 40.1 H x 10.2 D
• Shipping Dimensions (in./cm): 18.5 L x 18.0 W x 11.5 H / 47.0 L x 46.0 W x 30.0 H
• Shipping Weight (lbs/kg): 27.2 (12.3)
• UPC codes: 696471071481
• Compatible With: Portable generators with a 50-Amp 14-50R receptacle
• Warranty: 5 Year Limited
